Description
- Bus bar assemblies are available in a variety of configurations in both silverplated and unplated radius edged copper. Size of bus is rated 1000A. Per sq./in.
- Standard comcoded assemblies include mounting insulators, cable rack mounting clips, and grade 5 zinc plated bolts and hardware.
- Custom ground bus bar assemblies can be specially designed and manufactured to meet your exact specifications.
- Copper is stocked in sizes range from 1/4″ x 1″ to 1/2″ x 6″.
Applications
- Discharge Ground bars designed for use above all types of power distribution bays.
- Bus bars can be sized to match any ampacity requirement
- Custom bus assemblies are available for virtually any application.
- Addition to existing busbars and bus assemblies can be manufactured to meet your requirements.
26” Wide Bays
Click each link below to get the specifications for the product selected.
| # of Laminations/Amps | 1 Bays | 2 Bays | 3 Bays | 4 Bays |
|---|---|---|---|---|
| 1L/1500A | 1B26W1L | 2B26W1L | 3B26W1L | N/A |
| 2L/3000A | 1B26W2L | 2B26W2L | 3B26W2L | 4B26W2L |
| 3L/4500A | 1B26W3L | 2B26W3L | 3B26W3L | 4B26W3L |
| 4L/6000A | N/A | 2B26W4L | 3B26W4L | 4B26W4L |
| 5L/7500A | N/A | 2B26W5L | 3B26W5L | 4B26W5L |
| 6L/9000A | N/A | N/A | 3B26W6L | 4B26W6L |
| 7L/10,000A | N/A | N/A | 3B26W7L | 4B26W7L |
36” Wide Bays
Click each link below to get the specifications for the product selected.
| # of Laminations/Amps | 1 Bays | 2 Bays | 3 Bays | 4 Bays |
|---|---|---|---|---|
| 1L/1500A | 1B36W1L | 2B36W1L | 3B36W1L | N/A |
| 2L/3000A | 1B36W2L | 2B36W2L | 3B36W2L | 4B36W2L |
| 3L/4500A | 1B36W3L | 2B36W3L | 3B36W3L | 4B36W3L |
| 4L/6000A | N/A | 2B36W4L | 3B36W4L | 4B36W4L |
| 5L/7500A | N/A | 2B36W5L | 3B36W5L | 4B36W5L |
| 6L/9000A | N/A | N/A | 3B36W6L | 4B36W6L |
| 7L/10,000A | N/A | N/A | 3B36W7L | 4B36W7L |
